LDR

Remote Emergency Conversion Kit

The LDR emergency LED remote (independent) control gear allows maintained operation of high-power LED modules, and has been designed to be used in applications where you cannot fit an emergency conversion kit inside the luminaire, making it ideal for 600×600 panels and downlights where the pack can be positioned in the ceiling void. With colour coded push fit terminals, cable restraints and terminal covers it makes this a safe and installation friendly product for luminaires that need a remote pack solution.

The LDR emergency control gear incorporates a module/charger and a high temperature Lithium Iron Phosphate battery all in one housing. In the event of a mains failure an integral 2-pole relay disconnects the LED lighting load from the mains control gear and then connects it to the emergency control gear which operates the LED module at an optimum light output for the rated duration.

MICROPROCESSOR ENABLED FEATURES

The LED current in emergency mode is automatically adjusted for maximum light output and is constant for the entire rated duration.
Smart charging of Lithium Iron Phosphate batteries. NB: Lithium Iron Phosphate batteries offer long life (up to 10 years).
Details are logged of any mains failures to assist in the diagnostics of any site issues.
The LDR range is available with fully interoperable DALI control and reporting function. These DALI versions indicated by the suffix D, also provide automatic Self-Test when no DALI bus is connected.

In Self-test mode the function and duration tests will take place at randomised times. If required, duration testing can be programmed by turning the unswitched supply off and on 3 times in 10 seconds at the required time. Note: The function test will occur weekly at the same time.

LDR EMERGENCY CONTROL GEAR

To ensure the correct operation of each type of LED module the correct LDR equipment should be selected.

The total forward operating voltages of the LED module/arrays connected should be used to determine the appropriate LDR control gear. For the appropriate battery, indicator LED etc., see Order Codes. Note: All LDR modules can be equipped with SurePath BLE Bluetooth addressable Gateway modules.

SECTION	SUBJECT	PLASTIC HOUSED MODULE
Environmental	Protection against electric shock	Secondary outputs – SELV for output voltage < 100V
	Ingress protection	IP20
	Module rated operating ambient temperature	-20°C to 50°C
	Battery rated operating ambient temperature	0°C to 55°C
	Maximum case temperature	65°C
Mains Operation	Rated voltage supply	220/240V AC
	Mains frequency	50/60Hz
	Mains supply current	<18mA
	Mains supply power	4 watts
	Power factor	0.53C
	Mains overvoltage protection	320 volts for 1 hour
	Indicator LED	2 wire green colour – standard LDR 2 wire red/green – DALI LDR
	Maximum power that can be switched via relay contacts	150 watts
	Maximum current that can be switched via relay contacts	3 amps
	Maximum voltage that can be switched via relay contacts	250V AC/220V DC
Emergency Operation	Emergency duration	1 or 3 hours
	Battery chemistry type	LiFePO4
	Number and type of high temperature cells LDR90 and LDR90D	2 x LiFePO₄ 1.8Ah 18650 cells
	LDR90MO and LDR90MOD	2 x LiFePO₄ 2.3Ah 22650 cells
	LDR90HO and LDR90HOD	2 x LiFePO₄ 3.4Ah 26650 cells
	Battery recharge period	<24 hours
	Time to full illuminance	<0.5 seconds
	Short-circuit-proof battery connection, polarity reversal and deep discharge protection
	Battery charge current LiFePO₄ 1.8Ah, 2.3Ah and 3.4Ah cells — voltage dependent, constant current	0 – 150mA
	Battery discharge current range (at nominal battery voltage) LiFePO₄ 1.8Ah 18650 cells LiFePO₄ 2.3Ah 22650 cells LiFePO₄ 3.4Ah 26650 cells	360mA to 560mA (450mA) 475mA to 735mA (550mA) 650mA to 1000mA (750mA)
	Module operating current – see separate graphs. LDR90 and LDR90D	150mA to 19mA ±10%
	LDR90MO and LDR90MOD	220mA to 30mA ±10%
	LDR90HO and LDR90HOD	275mA to 41mA ±10%
	Module output voltage range (nominal power) LDR90 and LDR90D	12V to 90V (1.6W)
	LDR90MO and LDR90MOD	12V to 90V (2.6W)
	LDR90HO and LDR90HOD	12V to 90V (3.5W)
	EOFI – dependant on LED module type	0.12 to 0.25
	A record is kept of the number and length of emergency and mains operations – this information can be downloaded via the internal programming connector
	Mechanical	Module outside dimensions	(L) 270mm x (W) 76mm x (H) 35mm
		Minimum cut-out diameter	ø150mm
		Electrical connections	Push wire terminals
	Standards Compliance	EN61347-1, EN61347-2-7, EN61347-2-13 and EN62384	Yes
		EN62034, EN62386-101, EN62386-102* and EN62386-202*	Yes
		EN55015	Yes
		EN61547	Yes
Marks CE		Yes

NOTE: Values are subject to change *DALI/Self-test control gear only

Voltages	Order Codes
12 – 90V	LDR90, LDR90D, LDR90MO, LDR90MOD, LDR90HO, LDR90HOD

Remote Emergency Lighting Control Gear

Order Codes	Description
LDR90/K	12V to 90V Standard output module
LDM90D/K	12V to 90V DALI/Self-Test standard output module
LDR90MO/K	12V to 90V Medium output module
LDR90MOD/K	12V to 90V DALI/Self-Test medium output module
LDR90HO/K	12V to 90V High output module
LDR90HOD/K	12V to 90V DALI/Self-Test high output module
OPTIONS:
/ASSY	Prewired with all cables for connection to emergency luminaire
/FI	Prewired with free-issued cables for connection to emergency luminaire.

NOTE: The suffix D is for DALI/Self-Test control gear

Batteries

Order Codes	Description
B091T (for LDR90 and LDR90D)	1 x 2 cell stick – LiFePO₄ 1.8Ah 18650 cells (EN 62620 designation – IFpR1865 [1P2S] M060NA)
B092T (for LDR90MO and LDR90MOD)	1 x 2 cell stick – LiFePO₄ 2.1Ah 22650 cells (EN 62620 designation – IFpR2265 [1P2S] M060NA)
B093T (for LDR90HO and LDR90HOD)	1 x 2 cell stick – LiFePO₄ 3.0Ah 26650 cells (EN 62620 designation – IFpR2665 [1P2S] M060NA)
